System overview
Technical specifications
Note: Technical specifications of the EVOS
™
M5000 Imaging System are subject to change without
notice. For the latest product information, see the product page (thermofisher.com/evos).
Physical characteristics
Dimensions (W × H × D): 46 × 59 × 46cm (18 × 23 × 18in)
Weight: 16kg (35lbs.)
Footprint: Approximately 92cm × 92cm (36in × 36in)
Operating temperature: 4°–32°C (40°–90°F)
Operating humidity: <90%, non-condensing
Operating power: 100–240 VAC, 1.8A
Frequency: 50–60Hz
Electrical input: 12VDC, 5A
Hardware
Optics: Infinity-corrected optical system; RMS-threaded objectives with 45 mm parfocal distance.
Illumination: Adjustable intensity LED (>50,000‑hour life per light cube).
Light cubes (not included): 4-position chamber for 4 fluorescence cubes plus brightfield. Wide
selection of standard and specialty light cubes (see “LED light cubes” on page136).
Contrast methods: Fluorescence and transmitted light (brightfield & phase contrast).
Objective turret: 5‑position; front-mounted control.
Objectives (not included): Wide selection of high-quality LWD and coverslip-corrected objectives.
Condenser: 60‑mm long working distance condenser, 4 position turret with one clear aperture and
3phaserings.
Stage: Manual X-Y position-sensing stage. Travel range of 120 mm × 80 mm, drop-in inserts to receive
vessel holders and lock down holders to fix the sample in place.
Focus mechanism: Automated focus mechanism with sub-micron resolution.
LCD display: 18.5‑inch high-resolution LCD display (1920 × 1080 pixel resolution)
Camera: High-sensitivity monochrome CMOS camera (2048 × 1536 pixels, 3.2 Megapixels) with
3.45 µm pixels.
