Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G)Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 5-4
5. Service Application Software
The Service Screen will be displayed.
The main screen is divided into two panes, the Tree View Pane
and the
Fluid Schematic Pane
, with a Menu Bar across the top and a Status Bar
across the bottom.
Establishing Link
When the Service program first starts up, it must establish a link with the
analyzer control system. During this period, both the Tree View Pane and
the Fluid Schematic Pane are disabled, as well as many menu items. The
status of the link is shown in the status bar at the bottom of the screen.
Tip: While waiting for the connection to be established, you may want to
review the Event log. Using the mouse, select File, View Event Log.
