Iris Diagnostics, a Division of International Remote Imaging Systems, Inc.
iQ
®
200 Sprint™ Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 4-10
4. Adjustments
STD Verification Procedure
Test Configuration Tube Detect Range Your value
Glass tube with white label facing STD Between 0X90 – 0XFF
No tube Between 0X20 – 0X80
Range =
Using the hexadecimal calculator, subtract No Tube value from glass tube
with label value to obtain the range.
Range should be greater than 0X30Hex
Replace STD assembly if this test fails
