Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 2-2
2. Installation Procedures
Installation Requirements
Space Requirements
The
iQ
®
200 is a tabletop unit requiring free space on a standard (36 inch:
0.9m) height countertop of approximately 36 inches wide by 24 inches
deep (91cm by 61cm), with vertical clearance of at least 24 inches
(61cm).
With optional Load and Unload stations, the width requirement is 60
inches (147 cm.)
Workstation
The Workstation is composed of a desktop computer, video monitor,
keyboard and mouse requiring a suitable counter or desktop, providing
comfortable access and a good viewing angle. It is suggested that, if
possible, the WorkStation be placed in a work area, which can be semi-
darkened to increase screen display visibility and reduce glare.
The data connections are made between the
iQ
®
200 and the Workstation
(and the AX-4280 and the WorkStation, if applicable) via the special
cables provided.
Location
For most laboratories, the
iQ
®
200 is placed near an open benchtop work
area which can be used for preparation of urine tubes and sample racks.
All data transmissions from the
iQ
®
200 (and the Ax-4280, if used) are
routed to the Workstation, which manages and controls all
communications to the Laboratory Information System (LIS) via serial
connections.
Requirements
The
iQ
®
200 uses 90 to 240V AC, 50-60Hz input source. Neither voltage
nor frequency parameters are customer configurable. Uninterruptible
power supplies are recommended and available from Iris Diagnostics for
the
iQ
®
200 and the Workstation (and the AX-4280 if applicable) to maintain
system operation during short power outages and brownouts. This allows
for an orderly shutdown of instruments without the loss of data.
Installation
The
iQ
®
200 will be installed by a factory-trained representative from Iris
Diagnostics.
