Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 3-8
3. Components
Diaphragm Pumps
The diaphragm pumps are DC motor driven pumps located on the left
side of the instrument next to the sampler. They are from left to right:
1. Air Pump
2. Waste Pump
3. Rinse Pump
4. Fill Pump
Air Pump # 700-3877
This pump fills the air tank and is used for mixing the specimen through
the charge and air mix valves.
Waste Pump # 700-3809
This pump drains the waste well.
Rinse Pump # 700-3874
This pump fills the rinse well for cleaning the pipette.
Fill Pump # 700-3874
This pump maintains the level inside the Lamina tank.
