Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 3-15
3. Components
Air Valves
The Air Valves are located on the right front side of the instrument,
underneath the Optical Bench Assembly.
Air Mix Valve # 700-3887
The Air Mix Valve is used to mix the specimen
inside the sample tube.
Air Charge Valve # 700-3888
The Air Charge Valve is used to refill the
pressure in the Air Line for the mixing circuit.
