Page #66 background image
Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 3-21
3. Components
PCBA Summary
Many of the boards have LEDs indicating dynamic operating status of the
board and its controlling firmware.
Item No Board name or Sub assembly Number
# in
system
Location
1 HLCB 101-5057 1 Card cage
2 MSCB 101-5001 4 Card cage
3 DCVB 101-5043 2 Card cage
4 SSMB 101-5059 2 Card cage
5 Backplane 101-5003 1 Card Cage
6 SPA SIC 101-5004 1 Behind SPA
7 Pump SIC 101-5010 3 Behind Peri-pump
8 OBA SIC 101-5053 1 Side of Optical bench
9 STM SIC 101-5014 1
Above pumps left
panel
10 Pressure Transducer Board 101-5016 2
Valves mounting next
to optical bench
11 Power SIC 101-5020 1 Above cardcage
12 Rear Panel SIC 101-5058 1 Behind backplane
13 SM Status Board 101-5032 1 Top left front panel
14 STD Board 101-5034 1 Inside tube detector
15 FITD 101-5041 4
Waste well –
pressure transducer
16 FSV SIC 101-5045 1
Right board behind
lamina container
17 Do-All SIC 101-5046 1
Left board behind
lamina container
18 Waste Well Electrode Board 101-5047 1 Waste well
19 ESN Board 101-5049 42
20 SPA Opto Board 101-5052 1 SPA
21 Lamina ESN Bd 101-5048 1
Inside lamina
container
22 Waste Well FITD 101-5054 1 Waste well
23 OBA Focus Home 101-5055 1 Above CCD camera
