Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 3-30
3. Components
Do-All SIC # 101-5046
The Do-All SIC is used for interfacing to SMCS backplane J18 through a
40-wire ribbon cable, and providing a concentrating place for the cables
to all of the SMCS pressure transducers, the FITDs. The Do-All SIC is
mounted alongside the FSV SIC on the Fluid System Valve Assembly.
The Do-All SIC connectors are summarized on the table below.
Connect. Type Connects to Function
J1 40-pin ribbon header Backplane J18 Main signals to SMCS
J2 10-pin ribbon header Pressure Transducer #1 Pressure Transducer #1
J3 10-pin ribbon header Not used Not used
J4 10-pin ribbon header Not used Not used
J5 10-pin ribbon header Not used Not used
J6 12-pin female Not used Not used
J7 12-pin female Not used Not used
J8 12-pin female ESN FITD #3 P1 Specimen FITD
J9 12-pin female ESN FITD #4 P1 Waste Well FITD
J10 12-pin female Not used Not used
J11 12-pin female Not used Not used
J12 12-pin female Not used Not used
J13 12-pin female Not used Not used
J14 12-pin female Not used Not used
J15 12-pin female Not used Not used
J16 12-pin female Not used Not used
