Iris Diagnostics, a Division of International Remote Imaging Systems, Inc.
iQ
®
200 Sprint™ Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 4-12
4. Adjustments
Test Tube Centering Position
1. Open the STM branch from the Service Application menu tree.
2. Open Sequences and double click Initialize Rack “M1” and click OK
to execute the command. This positions the rack at the #1 tube
position.
3. From the top windows tool bar click Jog.
4. Select SPA Rotational Jog (The Velocity window will appear).
5. From the Jog Velocity window, select Home.
6. Using the up down arrows on the keyboard, center the pipette over
the center of test tube located in position #1 and then click Home then
“OK”.
7. From the SPA calibration table Double click on cal[1]:Double-click
here to auto set to store test tube #1’s new calibration value.
8. Click YES to confirm. Your new calibration value has now been set.
9. Immediately, double-click on Cal [2]: Double-click here to auto set
to auto set neg value of CAL 1.
10. Click YES to confirm.
11. Verify proper setting:
a. From the Service Application menu tree, under SPA Sequences
double click on “Pipettor Home “PH”.
b. Click OK to execute and verify the pipette tip is centered over the
Waste Well.
c. Double click on To Tube “TT” and click OK to execute and verify
the pipette tip is centered directly over the center of test tube #1.
12. Exit the service application.
