200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 3-24
3. Components
Signal Interface Concentrators (SICs)
While the SMCS card cage is the central brain of the SMCS, the control
and monitor signals of the SMCS must reach the electrical hardware that
it is measuring and controlling. To achieve this signal distribution, the
SMCS includes many “Signal Interface Concentrators’ PCBAs (SICs)
located throughout the SM.
The SICs provide a local place where the individual elements of the
particular subsystem of the SM have their electrical signals
“concentrated.” In some cases, there is ESN capability on the SICs.
Power SIC # 101-5020
The Power SIC provides a controlled interface between the DC power
supply, and the rest of the SMCS. It also provides controlled power to the
Strobe. The Power SIC is mounted atop the SMCS Cardcage, and
interfaces to backplane connector J15 through a 10-wire ribbon
connector, and to backplane connector J16, a 14-wire discrete wire
connector with large gauge wires carrying the actual power signals. The
Power SIC receives power directly from the DC Power supply via another
10-pin discrete wire connector. It also provides 12-volt regulated power
to the CCD camera. The power delivered to the Cardcage (and the rest
of the SMCS) is switched off and on by a logical signal from the SM front
panel “Standby” switch.
The Power SIC connectors are summarized in table below.
Connect. Type Connects to Function
J1
10-pin discrete female
header Molex MiniFit Jr
Power Supply DC
terminals Cable, P1
Unswitched regulated
power from power supply
J2
12-pin discrete female
header Molex MiniFit Jr
Cable to Backplane, J16
Switched/Fused power
to/from backplane
J3
10-pin ribbon header
w/locks
Cable to Backplane, J15 OBA SIC PIC16 control
J4 5-pin discrete header Cable to Video Camera
Power to camera, sync
from camera
J5 6-pin discrete header
Cable to Strobe power
supply
Strobe power, strobe
trigger
J6 3-pin discrete header
Cable to SM front panel
standby-switch
SMCS power off/on logic
control, +24V to indicator
LED in switch
J202
20-pin shrouded ribbon
header
(test programming cable)
PIC programming during
test
J203
10-pin shrouded ribbon
header
(test diagnostic cable)
Quad RS-232 driver bd
(test & diagnostics)
