Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 3-31
3. Components
Rear Panel SIC # 101-5058
The Rear Panel SIC provides the signal interface from the SM to the
external world through three DB9F connectors. It has in internal interface
to the internal Lamina Container level sensor. It provides an ESN
connector for the cooling fan, and a tethered ESN for identifying the
SMCS power supply. It connects to backplane connector J11 through a
26-wire ribbon cable (J1).
STM SIC # 101-5014
The STM SIC provides an interconnect capability between the two built-in
cables from the Arkray STM to the Microscopy Module. It interfaces to
the cardcage backplane connectors J20 and J21. It is also the interface
point for the diaphragm pumps of the Microscopy Module, the Specimen
Tube Detector (mounted on the STM), and the tethered ESNs for the
STM and for the Barcode Reader.
Other PCBAs
Lamina cable # 101-5048
The Lamina cable is used as part of the Lamina Container Assembly for
interfacing (and identifying) the float sensor switches of that assembly. It
provides for three of the four switches on the Lamina Container Assembly
to be summed through a weighted resistor network for a pseudo-analog
level detection scheme.
FITD PCBA # 101-5041
The PCB of this assembly is incorporated into two different
subassemblies for detecting the presence of water-based fluids in its
proximity.
SM Status Board PCBA # 101-5032
The SM Status board is both a display panel providing a user visual
interface and covers interlock switches for the top cover and the front
access door. It interfaces to SMCS backplane J10 through a 20-wire
ribbon cable.
STD PCBA # 101-5034
The Specimen Tube Detector board is a small electro-optics assembly
that is part of the Specimen Tube Detector. It senses the presence of a
