Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 2-5
2. Installation Procedures
Installation
To ensure safety, we advise you to read these installation instructions
very carefully and take all proper precautions.
Precautions
The entire unit weighs approximately 140 lbs (63.5k). The Load and
Unload Stations weigh 14 lbs (6.35) each. Choose a place to set up the
unit before completing its assembly.
If the unit must be moved, separate the Sampler from the analyzer before
moving. If these two units come apart while being carried, it may result in
injury or severe damage.
Always keep a distance of at least 2 inches (5 cm) between the rear of
the unit and the wall. If this distance is not maintained, the connecting
tubes and cables may overheat and / or be subjected to mechanical
stress.
Do NOT use power frequencies or voltage other than those specified in
this document. Connection to an inappropriate power source may
damage the instrument.
Make certain that the power supply for the
iQ
®
200 is from a dedicated line
that provides power to no other instruments or appliances. If power is not
clean and steady, a UPS and/or power conditioner is recommended.
Do NOT disassemble or modify the unit. Doing so may cause injury
and/or instrument malfunction.
Place the unit on a stable and level surface free of vibration. Failure to do
so may cause injury or malfunction of the unit.
Do NOT place the unit where it may be affected by chemicals, corrosive gases
or electronic noise. Doing so may cause injury or malfunction of the unit.
Do NOT place the unit where it may be affected by water, direct sunlight
or draft. This may yield incorrect results, and the unit may be damaged.
Select a room to set up the unit where the temperature can be controlled
between 50
o
F (10
o
C) and 86
o
F (30
o
C), and humidity in a range of 20% to
80%.
