Iris Diagnostics, a Division of Iris International, Inc.
iQ
®
200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 3-20
3. Components
Fuse &
LED
Fuse
Rating
Protects
power
through
Voltage and Function Protected
F15 D15 0.50A J14
+24V OBA focus stepper power (through
SSMB2)
F16 D16 0.50A J10 +5V Status Board power
F17 D17 0.50A J12 +5V FSV SIC power
F18 D18 0.50A J13 +5V Barcode Reader power
F19 D19 1.0A J12 +24V FSV SIC power
F20 D20 0.50A J17 +5V Pump SIC: Evacuation Pump
F21 D21 0.50A J24, J25 +24V Fan power
F22 D22 0.50A J16 +5V Power SIC Camera Circuits power
F23 D23 2.5A J16 +24V Strobe Power Supply power
F24 D24 1.0A J16 +24V Camera 24VDC to 12VDC Inverter power
