200 Sprint™ (2G) Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 3-26
3. Components
The FSV SIC connectors are summarized in table below.
Connect. Type Connects to Function
J1
40-pin ribbon
header
Backplane J12 Main signals to SMCS
J2 12-pin female Not used
J3 12-pin female Not used
J4 12-pin female Not used
J5 12-pin female Not used
J6 12-pin female CBV Operates CBV
J7 12-pin female ACV Operates ACV
J8 12-pin female LBV Operates LBV
J9 12-pin female DRV Operates DRV
J10 12-pin female AMV Operates AMV
J11 12-pin female PBV Operates PBV
J12 12-pin female EBV Operates EBV
J13 12-pin female Not used
J14 12-pin female Not used
J15 12-pin female Not used
J16 12-pin female Not used
