Iris Diagnostics, a Division of International Remote Imaging Systems, Inc.
iQ
®
200 Sprint™ Automated Urine Microscopy Analyzer Service Manual 300-4949 Rev A 01/2005 4-14
4. Adjustments
SPA pipette depth adjustment:
1. This procedure should only be done if it is determined that the test
tube depth positioning is incorrect. From the top windows tool bar
click Jog.
2. Select SPA Vertical Jog (The Velocity window will appear).
3. From the Jog Velocity window, select Home.
4. Using the up down arrows on the keyboard, lower the pipette into the
test tube until it’s 3mm from the bottom of the tube (the test tube can
be lifted to determine the distance the pipette is from the bottom of
the tube) then click Home then “OK”.
5. From the Service Applications menu tree SPA Calibration table
Double click on cal[3]:Double click here to auto set .
6. Click YES to confirm. The new calibration value has now been set.
7. From the SPA sequence menu, double-click PH-Pipettor Home.
8. Perform the “SPA pipette depth calibration check” procedure. If the
system hangs during this procedure, you will need to call Iris
Technical Service for cal [31] to determine this new calibration value.
9. Exit Service Mode.
