Juniper EX4300 Series

Table 88: Chassis Viewer for XRE200 External Roung Engines (Connued)
Field Descripon
Virtual Chassis port In the image, the colors listed below denote the Virtual Chassis port (VCP) status:
• Green—VCP is up and operaonal.
• Yellow—VCP is up but is nonoperaonal.
• Gray—VCP is down and nonoperaonal.
Mouse over the interface (port) to view more informaon.
LCD panel LCD panel congured for the LEDs on the ports. Mouse over the icon to view the
current character display.
Temperature The acve slots contain a gray temperature icon. Mouse over the icon to display
temperature informaon for the slot.
USB port Indicates the USB port for the switch.
NOTE: We recommend that you use USB ash drives purchased from Juniper Networks
for your EX Series switch.
PIC1 slot You can install a Virtual Chassis module in the PIC1 slot. Mouse over the Virtual Chassis
ports to display the port status details.
PIC2 slot You can install a Virtual Chassis module in the PIC2 slot. Mouse over the Virtual Chassis
ports to display the port status details.
Rear View of the XRE200 External Roung Engine
Fan modules Mouse over the fan modules to display status of the fans and airow direcon
informaon. For a Virtual Chassis, the status of the fans of the selected member switch
is displayed.
Power supplies Mouse over the power supply icons to display name, status, and descripon
informaon.
289
