Description One of the indicated peer addresses (local or remote) was invalid, so the key management
process (kmd) could not send a dead peer detection (DPD) reply to the remote peer.
Type Error: An error occurred
Severity error
Facility LOG_AUTH
KMD_DPD_INVALID_SEQUENCE_NUMBER
System Log Message Unable to send DPD reply: remote peer remote-address:remote-port provided invalid zero
sequence number to local peer local-address:local-port
Description The indicated remote peer (address and port) provided a zero sequence number, which
is invalid, to the indicated local peer (address and port). As a result, the key management
process (kmd) could not send a dead peer detection (DPD) reply to the remote peer.
Type Error: An error occurred
Severity error
Facility LOG_AUTH
KMD_DPD_NO_LOCAL_ADDRESS
System Log Message Unable to send DPD hello message from local peer local-address/local-port: address
not found in instance service-set
Description The indicated service set did not include an entry for the indicated local peer (address
and port), so the key management process (kmd) could not send a dead peer detection
(DPD) hello message from that peer.
Type Error: An error occurred
Severity error
Facility LOG_AUTH
KMD_DPD_REMOTE_ADDRESS_CHANGED
System Log Message Remote peer address for tunnel tunnel-name changed from old-address to new-address
Description The remote peer address in the configuration for the indicated tunnel changed to a new
value as indicated.
Type Event: This message reports an event, not an error
Severity notice
Facility LOG_AUTH
KMD_DPD_REMOTE_PEER_NOT_FOUND
System Log Message Unable to send DPD reply: DPD entry for remote peer remote-address:remote-port not
found in IKE server instance service-set
Copyright © 2010, Juniper Networks, Inc.328
Junos 10.3 System Log Messages Reference
