CAUTION: Do not leave the power supply slot empty for a long time while
the Junos Pulse Gateway is operational. Either replace the power supply
promptly or install a cover panel over the empty slot.
To remove a power supply from the Junos Pulse Gateway:
1. Place the antistatic bag or the antistatic mat on a flat, stable surface.
2. Attach the electrostatic discharge (ESD) grounding strap to your bare wrist, and
connect the strap to the ESD point on the chassis.
3. (MAG6610) Power off the Junos Pulse Gateway and disconnect power by performing
one of the following tasks:
•
If the AC power source outlet has a power switch, set it to the OFF (0) position.
•
If the AC power source outlet does not have a power switch, gently pull out the
male end of the power cord connected to the power source outlet.
4. Turn the adjustment nut of the power cord retainer counterclockwise until you can
see the power cord. Pull the power cord from the slot in the adjustment nut.
5. Remove the female end of the power cord from the AC appliance inlet on the power
supply faceplate.
6. Push the power cord retainer clip to one side of the appliance inlet. Squeeze the two
sides of the power cord retainer clip, and pull the L-shaped ends of the clip from the
holes on each side of the AC appliance inlet to completely remove the power retainer
clip.
7. Push the ejector lever until the power supply is unseated.
8. Grasp the power supply handle and pull firmly to slide the power supply halfway out
of the chassis.
Copyright © 2014, Juniper Networks, Inc.90
Junos
®
Pulse Gateway Hardware Guide
