Figure 39: Covering the MAG2600 Power Supply
4. Place the MAG2600 power supply and power supply holder onto the MAG-RK1U4
mounting tray and tighten the thumbscrew using a number-1 Phillips screwdriver.
The MAG2600 power supply should slide under the lip located on the back of the
MAG-RK1U4 mounting tray.
5. Route the cord through the opening located in the middle of the tray.
6. Remove the two rubber strips on the bottom of the MAG2600 and slide the MAG2600
back first into the MAG-RK1U4 mounting tray. The MAG2600 should be located directly
in front of its power supply.
71Copyright © 2014, Juniper Networks, Inc.
Chapter 9: Installing the Junos Pulse Gateway
