Juniper Junos Pulse MAG2600 User Manual

CHAPTER 3
Component Descriptions
•
Field-Replaceable Units in the Junos Pulse Gateway on page 17
•
AC Power Supply in the Junos Pulse Gateway on page 18
•
Cooling System and Airflow in the Junos Pulse Gateway MAG6610, MAG6611 on page 19
•
Integrated Access Service Modules on page 20
•
Chassis Management Card Overview on page 21
•
Status LEDs on the Junos Pulse Gateway on page 22
•
Ethernet Port LEDs on the Junos Pulse Gateway on page 22
Field-Replaceable Units in the Junos Pulse Gateway
Field-replaceable units (FRUs) are components that you can replace at your site. The
FRUs in the Junos Pulse Gateway are:
•
Power supplies
•
Fan trays
•
Integrated access service modules
•
Chassis management card
•
Hard drives for the MAG-SM360 (can be ordered separately if one drive fails)
NOTE: If you have a Juniper J-Care service contract, register any addition,
change, or upgrade of hardware components at
https://www.juniper.net/customers/csc/management/updateinstallbase.jsp.
Failure to do so can result in significant delays if you need replacement parts.
This note applies if you change the type of power supply or add a new type
of uplink module. It does not apply if you replace these components with the
same type of component.
Hot-swappable items are those items that can be removed and installed while the Junos
Pulse Gateway is powered up without affecting the Junos Pulse Gateway’s capabilities.
The following FRUs are hot-swappable:
•
Fan trays on the MAG6610 and MAG6611
17Copyright © 2014, Juniper Networks, Inc.
