• Monitoring the Junos Pulse Gateway Components Using LEDs on page 99
Installing a Fan Assembly in the MAG6610 and MAG6611
The fan tray is a hot-insertable and hot-removable field-replaceable unit (FRU) for the
MAG6610 and MAG6611. You can remove and replace the fan tray while the Junos Pulse
Gateway is running without turning off the power to the Junos Pulse Gateway. Fans are
located on the back of the Junos Pulse Gateway chassis.
NOTE: On the MAG6611, service modules are paired with fan trays and hard
drives. When moving a service module to a different slot, you must move the
associated fan trays and hard drives to the new location as well.
Before you install a fan try in the Junos Pulse Gateway, make sure that you understand
how to prevent ESD damage.
To install a fan tray in a Junos Pulse Gateway MAG6610 or MAG6611:
1. Attach the electrostatic discharge (ESD) grounding strap to your bare wrist, and
connect the strap to the ESD point on the chassis.
2. Remove the fan tray blank panel where you intend to install the fan tray.
3. Hold the handles of the fan tray, and align the tray with the fan tray guides on the fan
tray slot.
4. Slide in the fan tray until it is fully seated in the chassis.
Related
Documentation
Removing the Fan Tray on the MAG6610 and MAG6611 on page 91•
• Installing the Integrated Access Service Modules Overview on page 49
• Removing an Integrated Access Service Module on page 93
Installing a Hard Drive in the MAG6610 or MAG6611
The hard drive is a hot-insertable and hot-removable field-replaceable unit (FRU) on
the MAG-SM360 only.
NOTE: Service modules are paired with fan trays and hard drives. When
moving a service module to a different slot, you must move the associated
fan trays and hard drives to the new location as well.
The MAG-SM160 uses only one hard drive. The hard drive and service module are mated
together through the chassis midplane. When replacing the hard drive, insert the drive in
either the upper or lower slot where the service module is located. A drive cover should
be placed over the unused slot to maintain proper airflow.
Copyright © 2014, Juniper Networks, Inc.48
Junos
®
Pulse Gateway Hardware Guide
