Figure 3: MAG4610 Front Panel
g039113
MAG4610
3
2
5
4
1
Table 6 on page 9 lists the front panel components of the MAG4610.
Table 6: Junos Pulse Gateway MAG4610 Front Panel
ComponentNumber
Blank faceplate1
Console port2
USB port3
Ethernet ports 0, 1 and 24
LEDs (power, activity, alarm)5
Related
Documentation
Junos Pulse Gateway Features and Functions on page 4•
• Status LEDs on the Junos Pulse Gateway on page 22
• Junos Pulse Gateway MAG4610 Back Panel on page 9
Junos Pulse Gateway MAG4610 Back Panel
Figure 4 on page 9 shows the back panel of the MAG4610.
Figure 4: MAG4610 Back Panel
1
2
g039112
Table 7 on page 10 lists the back panel components of the MAG4610.
9Copyright © 2014, Juniper Networks, Inc.
