Mounting the Junos Pulse Gateway on Four Posts in a Rack or Cabinet
You can mount a Junos Pulse Gateway on four posts of a 19-in. rack or cabinet by using
the supplied rack-mount kit. (The remainder of this topic uses “rack” to mean “rack or
cabinet.”)
NOTE: If you are mounting the Junos Pulse Gateway on four posts, ensure
that the rack is 21.5-in. through 31.5-in. deep if you will mount the Junos Pulse
Gateway flush with the rack front and that the rack is 23.5-in. through 32.5-in.
deep if you will mount the Junos Pulse Gateway recessed 2-in. from the rack
front, thus ensuring that the protective earthing terminal is accessible through
the opening in the rear bracket.
Before mounting the Junos Pulse Gateway on four posts in a rack:
•
Verify that the site meets the requirements.
•
Place the rack in its permanent location, allowing adequate clearance for airflow and
maintenance, and secure it to the building structure.
•
Read the Security Products Safety Guide located on the Juniper Networks website.
•
Attach the mounting hardware to your Junos Pulse Gateway.
65Copyright © 2014, Juniper Networks, Inc.
Chapter 9: Installing the Junos Pulse Gateway
