NOTE: If you later move the MAG-SM160 service module to a different slot,
you must move its fan tray and hard drive to the new location as well.
Related
Documentation
Installing the Integrated Access Service Modules Overview on page 49•
• Installing a Fan Assembly in the MAG6610 and MAG6611 on page 48
• Installing a Hard Drive in the MAG6610 or MAG6611 on page 48
Installing the MAG-SM360 Kit
The MAG-SM360 kit includes:
•
One MAG-SM360 service module.
The cover plate on the left can be removed to accommodate the MAG-CM060 Chassis
Management Card.
•
Two fan trays.
•
Two hard drives (RAID 1 configuration).
To perform the initial installation of the MAG-SM360 kit:
1. Remove the faceplate on the Junos Pulse Gateway corresponding to the service
module slot where you want to install the MAG-SM360.
2. Remove the service module serial number sticker and install the MAG-SM360 in the
open slot.
3. Place the service module serial number sticker on the back panel of the Junos Pulse
Gateway chassis, directly behind the service module slot where you have installed
the MAG-SM360.
Service modules are paired with fan trays and hard drives. Hard drives have a serial
number label that matches the associated service module. Placing the service module
serial number sticker on the back panel of the Junos Pulse Gateway chassis helps you
ensure that you have the correct hard drive paired with the service module.
4. Remove the blank fan tray covers on the back panel of the Junos Pulse Gateway
directly behind the MAG-SM360 and install both fan trays in the slots.
NOTE: It is important that you install the fan trays directly behind the
MAG-SM360 to ensure proper airflow across the service module.
5. Remove the blank hard drive covers on the back panel of the Junos Pulse Gateway
directly behind the MAG-SM360 and install both hard drives.
Vertical slot order does not matter for the MAG-SM360 RAID1 drives. As long as the
drive signatures match the blade’s RAID 1 configuration, it accepts both drives
43Copyright © 2014, Juniper Networks, Inc.
Chapter 8: Installing Junos Pulse Gateway Components
