CHAPTER 10
Connecting the Junos Pulse Gateway
Tools and Parts Required for Junos Pulse Gateway Grounding and Power
Connections on page 75
Grounding the Junos Pulse Gateway on page 75
Connecting Power to an AC-Powered Junos Pulse Gateway on page 76
Connecting the Junos Pulse Gateway to a Management Console on page 77
Connecting the Junos Pulse Gateway to the Network on page 78
Connecting the MAG-CM060 CMC to a Network on page 78
Powering On an AC-Powered Junos Pulse Gateway on page 79
Powering Off the Junos Pulse Gateway on page 80
Using the Reset Button on the Service Modules on page 81
Tools and Parts Required for Junos Pulse Gateway Grounding and Power Connections
To ground and provide power to the Junos Pulse Gateway, you need the following tools
and parts:
Phillips (+) screwdrivers, numbers 1 and 2
2.5-mm flat-blade (–) screwdriver
7/16-in. hexagonal-head external drive socket wrench, or nut driver, with a torque range
between 23 lb-in. (2.6 Nm) and 25 lb-in. (2.8 Nm) tightening torque, for tightening nuts
to terminal studs on each power supply on a DC-powered Junos Pulse Gateway.
Wire cutters
Electrostatic discharge (ESD) grounding wrist strap
Grounding the Junos Pulse Gateway
NOTE: This step is not required for the MAG2600. Grounding is provided with
the three-prong power cord.
75Copyright © 2014, Juniper Networks, Inc.
