3. Using both hands, hold the front edge of the service module, and slide it completely
out of the chassis.
4. Place the service module in an antistatic bag or on an antistatic mat on a flat, stable
surface.
NOTE: Faceplates are required for proper cooling and airflow. If you do not
intend to replace the service module, cover the opening with a blank faceplate.
Related
Documentation
• Removing the Hard Drive on page 92
• Removing the Fan Tray on the MAG6610 and MAG6611 on page 91
• Installing the MAG-SM160 Kit on page 41
• Installing the MAG-SM161 Kit on page 44
• Installing the MAG-SM360 Kit on page 43
• Installing the MAG-SM361 Kit on page 45
