Table 71: FRU Power Requirements (continued)

Maximum Power RequirementPart NumberComponent

333 WDPCE-R-20GE-2XGE

DPCE-X-20GE-2XGE

Multi-Rate

Ethernet

EnhancedDPC

with SFP and

XFP or

Multi-Rate

Ethernet

Enhanced

Ethernet

Services DPC

with SFP and

XFP

335 WDPCE-R-Q-20GE-2XGEMulti-Rate

Ethernet

Enhanced

Queuing IP

Services DPC

with SFP and

XFP

320 WDPCE-R-40GE-TX

DPCE-X-40GE-TX

Tri-Rate

EnhancedDPC

or Tri-Rate

Enhanced

Ethernet

Services DPC

265 WMS-DPCMultiservices

DPC

FPCs

190 W (with PICs and optics)MX-FPC2FPC Type 2

265 W (with PICs and optics)MX-FPC3FPC Type 3

Documentation

Calculating Power Requirements for MX240 Routers on page 137•

• AC Power Supply Electrical Specifications for the MX240 Router on page 127

• DC Power Supply Electrical Specifications for the MX240 Router on page 143
