3.3 V 3293 mV
5.0 V 5053 mV
12.0 V 12200 mV
1.25 V 1260 mV
3.3 V SM3 3319 mV
5 V RE 5059 mV
12 V RE 12007 mV
Power 2
11.3 V bias PEM 11311 mV
4.6 V bias MidPlane 4827 mV
11.3 V bias FPD 11330 mV
11.3 V bias POE 0 11292 mV
11.3 V bias POE 1 11311 mV
Bus Revision 42
FPGA Revision 1
To check the status of a specific SCB, issue the show chassis environment cb command
and include the slot number of the SCB. The output is similar to the following:
user@host> show chassis environment cb 0
CB 0 status:
State Online
Temperature Intake 66 degrees C / 150 degrees F
Temperature Exhaust A 67 degrees C / 152 degrees F
Temperature Exhaust B 73 degrees C / 163 degrees F
Power
1.2 V 1153 mV
1.5 V 1417 mV
1.8 V 1704 mV
2.5 V 2375 mV
3.3 V 3138 mV
5.0 V 4763 mV
1.2 V Rocket IO 1160 mV
1.5 V Rocket IO 1408 mV
1.8 V RLDRAM 1717 mV
I2C Slave Revision 15
For more information about using the CLI, see the Junos OS documenation.
Related
Documentation
MX240 Host Subsystem Description on page 21•
• MX240 SCB Description on page 97
• MX240 Routing Engine Description on page 23
• MX240 Craft Interface Overview on page 12
Maintaining MX240 DPCs
Purpose For optimum router performance, verify the condition of the Dense Port Concentrators
(DPCs). The router can have up to three DPCs mounted horizontally in the DPC card cage
at the front of the chassis.
Copyright © 2017, Juniper Networks, Inc.382
MX240 3D Universal Edge Router Hardware Guide
