K-TRON KCM - KCM to KSC Wiring at K-Port 1- Digi Card

Docu-No.: 1090020601-EN Rev. 1.2.1 Page 103
Appendix 12
KCM wiring examples 12.4
12.4.4 KCM to KSC wiring at K-Port 1- Digi card
• The wiring may be different for other RS485 serial communication
cards.
• K-Port #1 is to be used only.
Fig. 12.3 KCM to KSC wiring with Digi RS485 serial port
KCM
K-Port1
123456
KSC-DB-9-RS485
1
2
3
4
5
6
7
8
9
Rx+
Tx+
Rx-
Tx-
COM
Rx+
Tx+
Rx-
Tx-
Vcc
J14
KCM K-Port KSC DB-9
2
3
4
5
6
6
7
8
9
Digi RS485
Serial
