K-TRON KCM - Drive Output Relays - J5; AC Interface Specific Output Relays - J9;J6

Docu-No.: 1090020601-EN Rev. 1.2.1 Page 39
Installation 4
Drive connection summary 4.10
4.10.4 Drive output relays - J5
4.10.5 AC Interface specific output relays - J9/J6
• Relay functions are programmable.
– Contact ratings: 250 Vac, 30 Vdc, 5 A, maximum
Terminal Function
J5-1 Relay #1, common
J5-2 Relay #1, N.O.
J5-3 Relay #1, N.C.
J5-4 Relay #2, common
J5-5 Relay #2, N.O.
J5-6 Relay #21, N.C.
J5-7 Relay #3, common
J5-8 Relay #3, N.O
• These relays are found only with the AC interface drive pcb.
– Relay K4 - Run Enable out
– Relay K5 - Alarm Reset out
– Relay K6 - AC line switching out- double pole
– Contact ratings: 250 Vac, 30 Vdc, 5 A, maximum
Terminal Function
J9-6 Relay #K4, COM
J9-7 Relay #K4, N.O.
J9-8 Relay #K5-COM.
J9-9 Relay #K5-N.O.
J6-1 Relay #K6 - N.O.
J6-2 Relay #K6 - N.O.
