Docu-No.: 1090020601-EN Rev. 1.2.1 Page 61
KCM Set-Up 5
DC drive set-up 5.3
5.3.3 450/1600 Watt DC drive pc board DIP switch settings
5.3.4 Additional jumper settings for 450 watt drive
Action Switch
Pos
Range
Tachometer Pulses
per revolution
1
Off = 100
On = 120
Tachometer signal
type
2
Off = single channel encoder
On = dual channel encoder
Drive address 3, 4, 5
(345) 000 = 0, 001 = 1, 010 = 2,
011 = 3 ..... 111 = 7
Not used 6
JP Normal
Position
Function
JP-4 1-2
[1-2] - SLM/KCM control
[2-3] - K10S protocol
Position [1-2] is normal
JP-5 1-2
[1-2] - SLM/KCM control
[2-3] - K10S protocol
Position [1-2] is normal
