12 Appendix
12.4KCM wiring examples
Page 104 Docu-No.: 1090020601-EN Rev. 1.2.1
12.4.5 KCM to KSC wiring at K-Port 1- Moxa card
• The wiring may be different for other RS485 serial communication
cards.
• K-Port #1 is to be used only.
Fig. 12.4 KCM to KSC wiring with Moxa RS485 serial port
KCM
K-Port1
123456
KSC-DB-9-RS485
1
2
3
4
5
6
7
8
9
Tx-
Tx+
COM
Rx-
Rx+
COM
Rx+
Tx+
Rx-
Tx-
Vcc
J14
KCM K-Port KSC DB-9
2
3
4
5
6
5
3
4
2
1
Moxa RS485
Serial
