4Installation
4.9 Host port connections
Page 36 Docu-No.: 1090020601-EN Rev. 1.2.1
4.9 Host port connections
4.9.1 Host port details
The host port can be configured for Profibus, Profinet ModbusPlus,
Modbus TCP, DeviceNet, Ethernet IP, Modbus RTU or AB DF1.
In each case, a specific communications card for that protocol is
required and must be installed into the Host port slot on the CPU
circuit card. In the case of Modbus RTU or AB DF1 protocols, the K-
Port1 is used.
4.9.2 Host connections for AB-DF1 and Modbus using K-Port1
For the host port protocols of Modbus TCP, Ethernet IP, DeviceNet,
ModbusPlus, ProfibusDP, Profinet, please refer to the following man-
uals for wiring details.
Protocol Document Number
DeviceNet 0590020609
Ethernet IP
Modbus TCP
Profinet
0590020610
ModbusPlus 0590020608
ProfibusDP 0590020607
Terminal Function Notes
J14-1 Power Unused
J14-2 Common Ground/common
J14-3 TxD+ RS485 TxD+
J14-4 TxD- RS485 TxD-
J14-5 RxD+ RS485 RxD+
J14-6 RxD- RS485 RxD-
