4Installation

4.10Drive connection summary

Page 38 Docu-No.: 1090020601-EN Rev. 1.2.1

4.10.2 Drive Internal Channel; Drive to CPU - J3

4.10.3 Drive SFT connections - J4/J7/J8

Terminal Function Notes

J3-1 Power + 24 Vdc power from Drive power supply

J3-2 Common Common from Drive power supply

J3-3 TxD+ Internal data channel to CPU

J3-4 TxD- Internal data channel to CPU

J3-5 RxD+ Internal data channel to CPU

J3-6 RxD- Internal data channel to CPU

• For the 450 watt dc motor drive, SFTs connect only to J4.

Terminal Color Functio

Notes

J4/7/8-1 Gray Power + 12 Vdc power from drive power supply

J4/7/8-2 Pink Common Ground/common from drive power supply

J4/7/8-3 Green TxD+ Internal data channel to SFT

J4/7/8-4 Yellow TxD- Internal data channel to SFT

J4/7/8-5 White RxD+ Internal data channel to SFT

J4/7/8-6 Brown RxD- Internal data channel to SFT
