K-TRON KCM - Setup Stepper Drive Boards; Setup AC Drive Boards

5 KCM Set-Up
5.7 GWB Application drive set-up
Page 68 Docu-No.: 1090020601-EN Rev. 1.2.1
5.7.4 Setup Stepper Drive Boards
The Stepper bd. has a 4 position DIP switch and due to needing two
other hardware flags, there are only two DIP switches used for setting
the address of the board as shown below.
5.7.5 Setup AC Drive Boards
The AC Interface board has a 6 position DIP switch. There are only
two DIP switches used for setting the address of the board, these are
switches numbered 5 and 6 as shown below.
0114
1005
1016
1107
1118
SW1 SW2 Ingredient Address
001
012
103
114
SW5 SW6 Ingredient Address
001
012
103
114
SW1 SW2 SW3 Ingredient Address
