5.2 Initial set-up for KCM drives
5.2.1 Drive jumper settings-all drive types listed
These settings must be made for all KCM drives. See below.
Notes:
• Digital input #1 or #2 must be set <True-On-1> to perform the
programmed function
• A <True> condition is at least a +5 Vdc input
• Different drives use different JP jumpers for the specified function
▲ Each drive board incorporates a DIP switch for programming. Pick
the correct chart for each.
▲ Each drive board also requires settings for on-board jumpers. See
drive specific charts for those as well.
▲ Off = <0>, On = <1> for each DIP switch position
▲ AC Drive, 450/1600W DC drive and vibratory DIP switch address
setting is different from the Stepper drive.
450 W
DC
1600 W
DC
Stepper
s
Vibrator
y
AC Normal
Position
Function
JP-3 JP-1 JP-1 JP-3 JP-1 1-2
[1-2] - RS485-4 wire to SFTs
[2-3] - RS485, 2 wire
Position [1-2] is normal
JP-1 JP-3 JP-2 JP-1 JP-3 1-2
[1-2] - Digital Input #1 input set for a
pull-up resistor. Input is active low.
[2-3] - Digital Input #1 input set for a
pull-down resistor. Requires an
active high to force off.
JP-2 JP-2 JP-3 JP-2 JP-2 1-2
[1-2] - Digital Input #2 input set for a
pull-up resistor. Input is active low.
[2-3] - Digital Input #2 input set for a
pull-down resistor. Requires an
active high to force off.
