K-TRON KCM - Vibratory Drive Set-Up

5 KCM Set-Up
5.6 Vibratory drive set-up
Page 64 Docu-No.: 1090020601-EN Rev. 1.2.1
5.6 Vibratory drive set-up
5.6.1 Vibratory drive pc board DIP switch settings
5.6.2 Vibratory drive adjustment
The displacement of the vibratory controller has to be adjusted via the
operator interface in the in the <MACHINE> menu, parameter
<Vibratory Span>.
Program the feedfactor values according to the following list.
 This values are set in the <CALIBRATION> menu
<FEEDFACTOR> sub-menu:
– MF@8% Drive Command
– MF@12% Drive Command
– MF@17% Drive Command
– MF@23% Drive Command
– MF@33% Drive Command
– MF@50% Drive Command
– MF@70% Drive Command
– MF@100% Drive Command
 Enter a starting setpoint according to the following chart <Setpoint
to enter>.
For loss-in-weight feeding or loss-in-weight batching only.
Action Switch Pos Range
Drive address (1-7) 1, 2, 3 (123) 000 = 0, 001 = 1, 010 = 2, 011 = 3 ..... 111 = 7
Operating mode 4
Off = normal operation
On = reset cold start frequency
 Set the <Vibratory Type> parameter in the MACHINE Menu
according to the type of vibratory drive. i.e. KV1...KV3.
Vibratory
Type
Setpoint to
enter
Expected
Displacement
Max.
Displacement
KV1 50 kg/hr 0.75 mm 1.0 mm
KV2 66 kg/hr 1.0 mm 1.5 mm
KV3 50 kg/hr 0.75 mm 2.0 mm
