Operation 7
Initial operation 7.1
7.1.1 KCM-SD LED status display
7.1.2 LED function listing
Fig. 7.1 KCM-SD LED status display
KCM
!
CAUTION – Disconnect power before opening .
115 /230 VAC , 50/60HZ, 2000 Watts (Max)
LED LED name Function
RUN LED Illuminates when the feeder is in operation.
STOP LED
Power check. Illuminates when the feeder
system has been switched on but no feeding
operations are currently in process.
ALARM LED
When an alarm is first detected, the LED il-
luminates.(Pending alarm condition)
If the alarm persists, once the alarm delay
time has passed, the LED flashes to indicate
a hard alarm. The alarm relay will activate if
programmed.
HEARTBEAT LED Blinks as the KCM CPU is running.
When using the KCM with a display and keypad mounted to its
surface (KCM-KD), refer to the operating manual for operational
information.
