Docu-No.: 1090020601-EN Rev. 1.2.1 Page 63
KCM Set-Up 5
Stepper drive set-up (all types) 5.5
5.5 Stepper drive set-up (all types)
5.5.1 Stepper motor programming table
5.5.2 Stepper drive pc board DIP switch settings
Feeder Type Max
Motor
RPM
Maximum
Power
Setting-W
Required Stepper Drive
BSP100 60 49
0000001430
0000005987
BSP125 60 49 or 194
0000004568 (194 watts)
0000001430 (49 watts)
0000005987
BSP135 60 194
0000004568
0000005987
BSP150-S 120** 194
0000004568
0000005987
KM-T12 150 43
0000005987
0000001430
Action Switch
Pos
Range
Drive address (0-3) 1, 2 (12) 00 = 0, 10 = 1, 01 = 2, 11 = 3
Output current at
STOP condition
3
Off = 0% current to stepper
motor during a stopped
condition.
On = 50% current to stepper
motor to hold its position during
a stopped condition.
Off = normal.
Tachometer signal
type
4
Off = single channel encoder
On = dual channel encoder
