Docu-No.: 1090020601-EN Rev. 1.2.1 Page 19
Assembly and Function 2
Structure 2.3
2.3 Structure
The KCM includes the following components, some which are
optional.
2.3.1 Enclosure
First, the pc board assemblies are housed in an Aluminium profile or
stainless steel housing with a swing-out cast cover. The enclosure is
designed to mount directly to a feeder or be located in a control panel.
All cabling is brought through the side of the housing incorporating
cable glands. The enclosure is Nema 4/IP 65 rated.
Wiring access is made through IP cable glands at the underside of the
KCM.
Fig. 2.1 KCM-KD
Fig. 2.2 KCM-SD
