12 Appendix
12.1Cable length specifications
Page 94 Docu-No.: 1090020601-EN Rev. 1.2.1
12 Appendix
12.1 Cable length specifications
12.1.1 DC motor cable lengths: 230 Vac
12.1.2 DC motor cable lengths: 115Vac
Motor Type Voltage
Rating
Current
Rating
Cable length for a
diameter of 1.5 mm
2
or
16 AWG, in meters
Cable length for a
diameter of 4 mm
2
or
12 AWG, in meters
Lenze 55 W 180V 0.46A 300 300
Lenze 70 W 180V 0.7A 300 300
Bison 95 / 98 W
180V-
200V
0.6A/
0.75A
300 300
Baldor 95 / 124 W
180V-
200V
0.86 A/
0.75 A
300 300
Lenze 250 W 180V 1.7A 300 300
Seramel 370 W 180V 2.6A 257 300
Stephan 370 W 180V 2.4A 278 300
Baldor 450 W 200V 2.5A 267 300
ABB 780 W 180V 4.1A 162 272
Baldor 1000 W 200V 5.6A 118 198
Baldor 2000/1600 W 200V
11.5A/
9.2A
56/71 95/120
Motor Voltage
Ratings
Current
Ratings
Cable length for a
diameter of 1.5 mm
2
or
16AWG, in meters
Cable length for a
diameter of 4 mm
2
or
12 AWG, in meters
Lenze 70 W 90V 1.25A 264 300
Lenze 250 W 100V 3.5A 93 156
Stephan 370 W 90V 4.9A 65 111
Baldor 450 W 100V 5.4A 59 100
Grossenbacher 700 W 90V 9.5 33 56
