Appendix 12
KCM I/O defaults 12.2
12.2.2 I-O function selection
Following the possible selection on the KSU-II operator interface for
the I/O assignment. Open I/O menu and select the desired sub-
menus.
Abbreviations:
• CONT = LWF, WBF, PID, VOL and SFM control (continuous)
• BATCH = LWB, WBB and SFB control (batch)
• LWF = loss-in-weigh feeder
• LWB = loss-in-weight batcher
• WBF = weigh belt feeder
• WBB = weigh belt batcher
• SFM = Smart Flow Meter flow indicator and controller
• SFB = Smart Flow Meter batcher
• PID = process controller
• VOL = volumetric controller
• XTR = Extrusion Control
For Analog output For Analog input
All
All
All
All
LWF/LWB/PID/SFM/SFB
WBF/WBB
WBF/WBB
WBF/WBB
LWB/WBB/SFB
LWB/WBB/SFB
PID
LWF/LWB
SFM/SFB
SFM/SFB
WBF/WBB
WBF/WBB
XTR
XTR
None
Setpoint
Massflow
Drive Command
Motor Speed
Feedfactor
Prefeeder
Beltloading
Belt Speed
Batch%
Batch Size
PVU Input
Net Weight
Net Chute
Net Divert
NetWeight1
Netweight2
FdrSetp
Level
All (Not XTR)
All
All
XTR
XTR
XTR
XTR
None
Setpoint
CPU 0-10 kHz
Extern
Hauloff
XtrSetpt
XtrSpeed
Pressure
