K-TRON KCM - 4.10.19 AC Interface Analog I-O - J9

Docu-No.: 1090020601-EN Rev. 1.2.1 Page 45
Installation 4
Drive connection summary 4.10
4.10.19 AC interface analog I-O - J9
Terminal Function Notes
J9-1
Analog current output (+)
For drive command control to external drive at 500 mA dc
maximum source.
J9-2 Analog current output (-) For drive command control to external drive.
J9-3
Frequency Out (+)
For drive command control to external drive. (5 Vdc
amplitude)
J9-4 Frequency Out (-) For drive command control to external drive.
J9-5 +24 Vdc Maximum current 500 mA, fused
J9-6 See section 4.10.5
J9-7 See section 4.10.5
J9-8 See section 4.10.5
J9-9 See section 4.10.5
J9-10 Common
