Docu-No.: 1090020601-EN Rev. 1.2.1 Page 37
Installation 4
Drive connection summary 4.10
4.10 Drive connection summary
The first group of connections, tables 4.10.1 to 4.10.4 are common for
all drive types.
4.10.1 Drive digital inputs- J1
See programming manuals for application information.
Input #1/#2 functions are programmable.
Terminal Function Notes
J1-1 + 24 Vdc DC voltage supply at 500 mA-fused.
J1-2 Safety Switch Input Connect J1-2 to J1-1 to energize internal safety relay.
J1-3 + 24 Vdc Same as J1-1
J1-4 Drive Enable Sig (+) Connect J1-4 to J1-3 to permit a run enable. See next.
J1-5 Drive Enable Sig (-) Connect J1-5 to J1-6 to permit a run enable
J1-6 Common Ground or common connection
J1-7 + 24 Vdc Same as J1-1
J1-8 Input signal #1 This input is programmable
J1-9 Common Same as J1-6
J1-10 + 24 Vdc Same as J1-1
J1-11 Input signal #2 This input is programmable
J1-12 Common Same as J1-6
