12.2 KCM I/O defaults
The following table shows the standard bit I/O assignment. If other
function are needed reassignment is possible with the operating unit.
12.2.1 Default KCM Programmable I-O table.
In/output Location LWF/LWB WBF SFM PID/VOL
CPU Input 1
CPU Input 2
CPU Input 3
CPU Input 4
J8-1
J8-2
J8-3
J8-4
Start
Stop
ALS
None
Start
Stop
ALS
None
Start
Stop
ALS
None
Start
Stop
ALS
None
CPU Output 1
CPU Output 2
CPU Output 3
CPU Output 4
J8-6
J8-7
J8-8
J8-9
Run
Alarm Relay
ALS Out
Drive Enable
Run
Alarm Relay
ALS Out
Drive Enable
Run
Alarm Relay
ALS Out
Drive Enable
Run
Alarm Relay
ALS Out
Drive Enable
CPU Freq Input J9-1/2 Ext. Setpoint Ext. Setpoint Ext. Setpoint Ext. Setpoint
CPU Analog Output J9-3/4 None None None None
CPU Analog Input J9-5/6 None None None None
Drive Relay 1
Drive Relay 2
Drive Relay 3
J5-1/2/3
J5-4/5/6
J5-7/8
Feeder Run
Refill
Alarm
Feeder Run
None
Alarm
Drive enable
None
Alarm
Feeder Run
None
Alarm
Drive Input 1
Drive input 2
J1-8
J1-11
None
None
None
None
None
None
None
None
