Docu-No.: 1090020601-EN Rev. 1.2.1 Page 95
Appendix 12
Cable length specifications 12.1
12.1.3 Cable lengths for speed feedback signals
Notes:
• The Scale Interface pc board (SIB) pc board is located in a junction
box on the side of the feeder and is used when the KCM is not
mounted on the feeder.
• The cable must be fully shielded.
• Use the Scale Interface pc board (SIB) if more than 30 meters of
transmission distance between feeder and controls is required.
Pick-Up/Encoder Pick-up Type Cable length
without Line-Driver
in SIB., in meters
Cable length
with Line-Driver* in
SIB., in meters
Jaquet FTG 1088.01 Ex 30 300
W+S (Lenze-Motor 55W) HGI 490 063600 30 300
HP (Bison-Motor 95/98W HEDS 5600 C06 30 300
HP (Baldor Motor 95/124W) HEDS 5600 C06 30 300
US Digital HEDS 9100-H00 30
If motor coil and
encoder signals are
in the same cable the
signals must be
individually shielded.
See section 12.4.14
for more information.
100
With encoder signals
in separate shielded
cable.
