4 Installation
4.1 Unpacking
Carefully unpack the KCM from the shipping container and check that
all items have been supplied. The KCM may be mounted on the feed-
er.
4.2 Tools
▲ Protect the explosion-proof control from direct sunlight.
▲ Ensure that the KCM is connected and put into operation only by
authorized personnel.
▲ KCM mounting must be vertical and protect from direct sunlight..
▲ Minimum lateral mounting spacing between KCMs is 25 mm.
(support rail to support rail)
▲ Minimum vertical mounting spacing between KCMs is 75 mm.
(case to case)
▲ If no SFT Interface board is used, the KCM must be mounted
within 30 m (100 Ft.) of the feeder.
The following tools are recommended when working with the KCM:
• Medium phillips screwdriver
• Small blade jewelers screwdriver
• Medium blade screwdriver
• 18 mm open end wrench
• 24 mm open end wrench
