4Installation
4.10Drive connection summary
Page 44 Docu-No.: 1090020601-EN Rev. 1.2.1
4.10.17 AC interface drive power - J6
4.10.18 AC interface frequency feedback - J2
Single Ended Encoder Signal
Differential Encoder Signal
Terminal Function Notes
J6-1 Switched line power L2 to
remote motor contactor
Fused and switched through relay K6 from the input line
power at J6-7.
J6-2 Switched line power L1 to
remote motor contactor
Fused and switched through relay K6 from the input line
power at J6-8.
J6-3 PE/GRD Earth/ground
J6-4 PE/GRD Earth/ground
J6-5 PE/GRD Earth/ground
J6-6 Neutral Neutral leg of a 115 Vac line or 230 Vac
J67 L2 Second leg of a 230 Vac line
J6-8 L1 Line input (hot) either 115 Vac or 230 Vac
• For AC Drive frequency feedback input:
– Vmax < 25.0 Vdc, Vmin > 4.0 Vdc, Ion (typ) > 15 mA
Terminal Function Notes
J2-1 + 5 Vdc + 5 Vdc power at 100 mA for sensor power
J2-2
Connect to J2-1
Positive side of the opto isolator. Configured for current
sinking tachometer.
J2-3 Tachometer Frequency
Input
Frequency input from the tachometer, negative side of the
opto isolator.Configured for current sinking tachometer.
J2-4 Common Common for sensor
Terminal Function Notes
J2-1 + 5 Vdc + 5 Vdc power at 100 mA for sensor power
J2-2 Freq (+) Frequency input from the tachometer.
J2-3 Freq (+) Frequency input from the tachometer.
J2-4 Common Common for sensor
