Docu-No.: 1090020601-EN Rev. 1.2.1 Page 79
Maintenance 9
Battery replacement 9.4
9.4 Battery replacement
1. Switch off power to the KCM.
2. Wait for three minutes prior to opening KCM cover.
3. Open KCM.
4. Replace battery BT1.
5. Re-install cover.
6. Return KCM to service.
▲ The front cover is Part of the ignition protection and it must not be
opened unless power has been removed and no explosive
atmosphere is present.
▲ Danger of an explosion exists if battery is incorrectly replaced.
▲ Order Batteries directly from K-Tron 9104-40001
or:
• Is it recommend to replace batteries every five years or when an
alarm on the KCM states ‘Battery Low’.
• Replace battery only with the same or recommended equivalent
type.
• Dispose of used battery according as required by law.
Manufacturer Renata Energize Duracell
Type CR2032 CR 2032 DL2032D
