Docu-No.: 1090020601-EN Rev. 1.2.1 Page 43
Installation 4
Drive connection summary 4.10
4.10.14 Vibratory drive power - J6
4.10.15 Vibratory drive feedback - J2
4.10.16 Vibratory drive phase angle correction
Switch the two leads to J2 terminal block if the KV drive does not
control properly.
Note:
• The alarm MDU_Polarity(20) will occur if this change is to be made.
Terminal Function Notes
J6-1
Vibratory feeder coil (-)
Variable amplitude and frequency power to vibratory feeder
drive coil.
J6-2
Vibratory feeder coil (+)
Variable amplitude and frequency power to vibratory feeder
drive coil.
J6-3 Vibratory feeder ground/
PE
Earth/ground
J6-4 PE/GRD Earth/ground
J6-5 PE/GRD Earth/ground
J6-6 Neutral Neutral leg of a 115 Vac line or 230 Vac
J6-7 L2 Second leg of a 230 Vac line
J6-8 L1 Line input (hot) either 115 Vac or 230 Vac
Terminal Function Notes
J2-1
Feedback coil (+)
Signal from displacement measurement coil from the KV vibratory
feeder.
J2-2
Feedback coil (-)
Signal from displacement measurement coil from the KV vibratory
feeder.
